Hyundai ILOAD 2009
The 2009 Hyundai iLoad carries a braked towing capacity of up to 2000 Kg, but check to ensure this applies to the configuration you're considering.
Hyundai ILOAD 2009 Dimensions
Dimensions for the 2009 Hyundai iLoad are dependent on which body type is chosen. The maximum width and height is 1920mm x 1935mm and can vary on the basis of model.
| Hyundai iLoad Model | Body Type | Height x Width x Length | Ground Clearance | |
|---|---|---|---|---|
| base | Commercial | 1935x1920x5125 mm | 190 mm | |
| Crew | Commercial | 1935x1920x5125 mm | 190 mm | |
Hyundai ILOAD 2009 Q&As
Check out real-world situations relating to the Hyundai ILOAD 2009 here, particularly what our experts have to say about them.
-
Hyundai iLoad 2009: Can I replace the engine?
I don't believe there is one, but try the Castlemaine Rod Shop (03 5472 2853) as they do a lot of that sort of thing and might have something they could help you with. If they don’t you could have the conversion done by a Vicroads accredited engineer, but it would an expensive exercise and I would think it would be more economical to buy a replacement diesel engine for your van.
Show more -
Hyundai iLoad 2009: Turbo actuator fault
If it were the actuator that has failed again I would think you had a strong claim for a replacement. The part that was fitted has a warranty, and if it has failed, the warranty on the actuator should cover the replacement.
Show more -
Hyundai iLoad 2009: Diesel filter clogged
It's always worth starting with the basics when trying to trace the cause of a problem, and they are fuel and spark. There's no ignition with a diesel, so fuel should be the focus. Good to see mechanics that know their stuff.
Show more
Hyundai ILOAD 2009 Price and Specs
Pricing guides
| Hyundai Iload Model | Body Type | Specs | Price from | Price to | |
|---|---|---|---|---|---|
| (base) | Commercial | 2.5L Diesel 5 SP AUTO | $11,880 | $15,840 | |
| (base) | Commercial | 2.5L Diesel 5 SP MAN | $9,680 | $13,200 | |
| (base) | Commercial | 2.4L PULP 5 SP MAN | $9,020 | $12,760 | |
| Crew | Commercial | 2.5L Diesel 5 SP AUTO | $12,430 | $16,610 | |
Hyundai ILOAD 2009 Towing capacity
The Hyundai iLoad’s towing capacity ranges from 1500kg to 2000kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.
| Hyundai iLoad Model | Body Type | Specs | Braked Capacity | |
|---|---|---|---|---|
| base | Commercial | 2.4L,PULP,5 SP MAN | 1500kg | |
| Crew | Commercial | 2.4L,PULP,5 SP MAN | 1500kg | |
| base | Commercial | 2.5L,Diesel,5 SP MAN | 2000kg | |
| Crew | Commercial | 2.5L,Diesel,5 SP MAN | 2000kg | |
Hyundai ILOAD 2009 Wheel size
Wheel size for the 2009 Hyundai iLoad will vary depending on model chosen, although keep in mind that many manufacturers offer alternate wheel sizes as options on many models.The wheel size available will alter the range of tyres available to be fitted. Standard wheel sizes on the Hyundai iLoad spans from 16x6.5 inches.
| Hyundai iLoad Model | Body Type | Front Tyre Size | Front Rim | Rear Tyre Size | Rear Rim | |
|---|---|---|---|---|---|---|
| base | Commercial | 215x70 R16 | 16x6.5 inches | 215x70 R16 | 16x6.5 inches | |
| Crew | Commercial | 215x70 R16 | 16x6.5 inches | 215x70 R16 | 16x6.5 inches | |
Hyundai ILOAD 2009 Fuel consumption
Fuel consumption for the 2009 Hyundai iLoad is dependent on the type of engine, transmission, or model chosen. The Hyundai iLoad currently offers fuel consumption from 8.5 to 10.1L/100km. The Hyundai iLoad is available with the following fuel types: PULP and Diesel.
| Hyundai iLoad Model | Body Type | Specs | Fuel Consumption | |
|---|---|---|---|---|
| Crew | Commercial | 2.4L,PULP,5 SP MAN | 10.1L/100km | |
| base | Commercial | 2.5L,Diesel,5 SP MAN | 8.5L/100km | |
| base | Commercial | 2.5L,Diesel,5 SP AUTO | 9.6L/100km | |
| base | Commercial | 2.4L,PULP,5 SP MAN | 10.1L/100km | |
