Ford Courier 1994

What's on this page

Ford Courier 1994

The 1994 Ford Courier range of configurations is currently priced from $2,420.

The 1994 Ford Courier carries a braked towing capacity of up to 1500 Kg, but check to ensure this applies to the configuration you're considering.

Ford Courier 1994 Q&As

Check out real-world situations relating to the Ford Courier here, particularly what our experts have to say about them.

  • Brown oil-like substance in my 1989 Ford Courier radiator

    It certainly sounds like it could be a blown head gasket that is allowing the car’s coolant to mix with its engine oil. A brown, oily looking fluid in the radiator is a sign that this may have occurred. Check the engine oil next. If it’s milky and discoloured, then that’s another sign of a blown head gasket. That said, just because there’s no evidence of coolant in the engine oil, doesn’t necessary mean the head gasket is intact.

    So, before you rip into the engine and remove the cylinder head, make sure the gasket is actually the problem. This can be done with a chemical-based test which samples the coolant and determines whether there’s any contamination in it that can be traced to the engine’s combustion. If it’s there, then the head gasket is almost certainly faulty.

    The 1989 Courier was available with a 2.0-litre diesel engine or a range of four-cylinder petrol engines ranging from 2.0 to 2.2 and even 2.6 litres in capacity. You’ll need to ascertain which engine your vehicle has and then obtain the correct workshop manual for that specific powerplant. The good news is that all these engines were relatively simple and changing a head gasket should not be too taxing for anybody with average mechanical skills.

    Show more
  • Issues starting my 2002 Ford Courier GL

    If the vehicle is running at all, then the fuel pump is working, It’s that simple. And while you’ve changed the pump twice in recent times, have you also replaced the pick-up tube that dangles from the pump and reaches down into the deepest depths of the fuel tank?

    Sometimes, these tubes can split (and the split can be hard to see) allowing the pump to suck air rather than fuel if the split is exposed. Which could mean that your car, when parked on a slope sufficient to cover with fuel the split in the pick-up, started no problem. But, when parked on the flat and the fuel in the tank allowed to pool away from the pick-up tube, the split was exposed and the pump was sucking air again. It sounds like a long shot, but it has definitely happened before today.

    Show more
  • My 2006 Courier won't get up to 110km/h

    The piece of the puzzle you've left out here is whether your Courier has a petrol or diesel engine. If it's the former, you could simply be looking at a worn out engine. These four-cylinders worked pretty hard and once they become worn, they start to blow smoke and lose power. That said, it could be something as simple as a blocked air filter element or a slack fuel pump.

    If the vehicle has a diesel engine, there's a chance the intake system is choked up with black soot and oil fumes which eventually narrow the engine's breathing passages like cholesterol blocks a person's blood vessels. Suddenly, the air can't get into the engine properly and the engine loses power as a result. Again, though, it could be something completely different and apparently random such as the turbocharger's plumbing having fallen off, leaving the engine with no boost.

    A word of warning, though, about driving a diesel Courier flat out everywhere. These engines were under-cooled and are notorious for overheating. Driving it with the throttle pedal on the floor is asking for problems.

    Show more
  • Why does my 2000 Ford Courier billow black smoke when it starts?

    The best way to test the operation of a fuel-injected car’s sensors is to have the vehicle scanned at a workshop with the necessary computer gear. The error codes that are revealed will tell you exactly what’s going on and save you the time and money of replacing bits and pieces until you find the actual culprit.

    As for your symptoms, black smoke from the exhaust usually indicates a too-rich air:fuel mixture which could be the result of worn injectors, incorrect fuel pressure or a faulty temperature sensor. There are other causes, but those are the ones I’d investigate first. After a scan, of course.

    Show more
See All Ford Courier Q&As
Disclaimer: You acknowledge and agree that all answers are provided as a general guide only and should not be relied upon as bespoke advice. Carsguide is not liable for the accuracy of any information provided in the answers.

Ford Courier 1994 Dimensions

Dimensions for the 1994 Ford Courier are dependent on which body type is chosen. The maximum width and height is 1705mm x 1715mm and can vary on the basis of model.

Dimensions for the Ford Courier 1994 Dimensions  include 1715mm height, 1705mm width, 4920mm length.
Ford Courier Model Body Type Height x Width x Length Ground Clearance
base Ute 1565x1670x4795 mm 170 mm
base Ute 1565x1670x5000 mm 170 mm
XL Ute 1565x1670x4715 mm 170 mm
base Ute 1570x1670x4715 mm
See All Ford Courier 1994 Dimensions

Ford Courier 1994 Wheel size

Wheel size for the 1994 Ford Courier will vary depending on model chosen, although keep in mind that many manufacturers offer alternate wheel sizes as options on many models.The wheel size available will alter the range of tyres available to be fitted.

Ford Courier Model Body Type Front Tyre Size Front Rim Rear Tyre Size Rear Rim
base Ute 185Rx14C 14x5 inches 185Rx14C 14x5 inches
XL Ute 185Rx14Cx5 14x5 inches 185Rx14Cx5 14x5 inches
base Ute 185Rx14C 185Rx14C
XL Ute 14x185 inches 14x185 inches
See All Ford Courier 1994 Wheel Sizes

Ford Courier 1994 Price and Specs

The Ford Courier 1994 is currently available from $2,420 for the Courier XL up to $7,700 for the Courier XL (4X4).

Pricing guides

$5,060
Based on third party pricing data
Lowest Price
$2,420
Highest Price
$7,700
Ford Courier Model Body Type Specs Price from Price to
(4X4) Ute 2.6L ULP 5 SP MAN 4X4 $2,860 $4,400
(base) Ute 2.2L Diesel 5 SP MAN $2,640 $4,070
(base) Ute 2.6L ULP 5 SP MAN $2,640 $4,070
XL Ute 2.2L Diesel 5 SP MAN $2,640 $4,070
See All Ford Courier 1994 Pricing and Specs

Ford Courier 1994 Towing capacity

The Ford Courier’s towing capacity ranges from 900kg to 1500kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.

Ford Courier Model Body Type Specs Braked Capacity
base Ute 2.6L,ULP,5 SP MAN 1500kg
base Ute 2.2L,Diesel,5 SP MAN 1500kg
base Ute 2.2L,Diesel,5 SP MAN 900kg
XL Ute 2.2L,Diesel,5 SP MAN 900kg
See All Ford Courier 1994 Towing Capacity

Ford Courier 1994 Fuel consumption

Fuel consumption for the 1994 Ford Courier is dependent on the type of engine, transmission, or model chosen. The Ford Courier is available with the following fuel types: ULP and Diesel.

Ford Courier Model Body Type Specs Fuel Consumption
(4X4) Ute 2.6L,ULP,5 SP MAN 4X4
XL Ute 2.2L,Diesel,5 SP MAN
base Ute 2.2L,Diesel,5 SP MAN
base Ute 2.6L,ULP,5 SP MAN 12.5L/100km
* Combined fuel consumption See All Ford Courier 1994 Pricing and Specs
